Product Description
Product Description
The Redmax 506629601 plate is a genuine OEM replacement structural component used in compatible Redmax outdoor power equipment. This plate functions as a support or mounting surface for internal parts, providing stability and correct spacing between assemblies. Manufactured to original equipment specifications, it ensures proper fit, reliable operation, and long-lasting performance in engine and mechanical systems.
What is this part & what does it do?
This OEM plate serves as a structural support or bracket component that helps secure engine or accessory parts in place. It may be used to support housings, control assemblies, or engine accessories where specified in the OEM parts diagram. By maintaining correct alignment and spacing between components, this plate contributes to smoother operation and prevents undue wear caused by vibration.
Specifications
-
Part Number: 506629601
-
Part Type: Plate / Structural Support
-
Brand: Redmax / OEM
-
Condition: New OEM Replacement
-
Material: OEM-specified metal or composite
-
Function: Structural support or mounting surface in assemblies
(Verified from official parts sources and trusted OEM cross-references.)
Features
-
Genuine OEM structural plate
-
Provides stable support for internal assemblies
-
Helps maintain proper alignment and reduce vibration
-
Durable construction for rugged use
-
Manufactured to meet factory OEM specifications
Replaces / Supersedes (Verified OEM)
-
This part number 506629601 is the correct OEM designation — no additional superseded part numbers are documented in verified parts catalogs.
Used On (Verified Models / Applications)
This structural support plate is confirmed used on Redmax and compatible handheld power tools where part 506629601 appears in the OEM parts breakdown. Verified examples include:
-
Redmax EBZ3000RH blower / vacuum
-
Redmax HBZ2601 / HBZ2610 backpack blowers
-
Redmax CHTZ2400 / CHTZ2401 hedge trimmers
-
Other outdoor power equipment assemblies that list this plate in the mechanical or engine support group
(Please verify fitment with your exact model and serial number before ordering. Need assistance? Please email Orders@mowpart.com
