Product Description
Specs
Engine Type4-cycle, gasoline, OHV, cast iron cylinder liners, aluminum block, electronic fuel injection
Model
ECH749
Displacement
cm3 (in3)
747 (45)
Bore
mm (in)
83 (3.3)
Stroke in (mm)
mm (in)
69 (2.7)
Maximum Torque
Nm (lb-ft)
54.2 (40)@2400RPM
Dry Weight
kg (lbs)
49 (108)
Oil Capacity
L (US qt)
1.9 (2)
Compression Ratio
9.1:1
Lubrication
Full pressure w/full-flow filter
Engine Type
Commercial
Dimensions L x W x H
mm (in)
376x480x622 (14.8x18.9x24.5)
1 Performances measured according to ISO 14396 without final intake and exhaust line.Actual engine performances may be affected by accessories (intake and exhaust line, charging , cooling fan, etc.), application, ambient operating conditions (temperature, humidity and altitute) and other factors.
